Model raqami: MNF601EA1-1
MNF601EEA1-1 ning harorati 0 ~ 50 ° C, saqlash harorati -20 ~ 60 ° C. MNF601EEEA1-1 ning displeyi 3840 (RGB) × 2160 (UHD), jihati 16: 9 (kengligi) va piksellar RGB vertikal chiziqlarda joylashtirilgan. MNF601EEA1-1 displey maydoni 345,6 × 194.4 (kengligi × balandligi) mm, tashqi ko'rinishi 350,72 (balandligi) × 2,6 (qalinligi) mm.
Turli ekologik ehtiyojlarni qondirish uchun standartlashtirish va sozlash.
Rising-Star Umumiy ko'rgazma panellari ultra yuqori aniqlikdagi, tashqi ko'rinishi va uzoq navli hayotga ega. Mahsulot dasturlari Avtomatik telefoniy (ATM), Terminal Sotish dastgohlari, interfaol ma'lumotlarning kiosklari (Kiosk), Siyosat-ko'ngilochar kiosklar, tibbiy asbob-kulgi mashinalari, parvozi avtomatlashtirish Marine kutmoqda.
| brand | CSOT | Model name | MNF601EA1-1(CSO1500) |
| size | 15.6inch | Screen type | LTPS TFT-LCD,LCD module |
| resolution ratio | 3840(RGB)×2160, UHD | Pixel configuration | RGB vertical bar |
| Display Area | 345.6×194.4(H×V)mm | Surface treatment | mirror(Haze 0%)，Hard coating (3H) |
| Visual size | / | Contrast Ratio | 1500:1 (Typ.) (TM) |
| Brightness(cd/m²) | 600cd/m²(Typ.)or customized | Outline dimension | 350.72×216.07×2.6(H*V*D)mm |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | work environment | Storage temperature: -20 to 60 °C Operation Temperature: 0 to 50 °C |
| Signal interface | eDP (4 Lanes),eDP1.4,HBR2 (5.4G/lane),40 pins,erminal |
|
|
| supply voltage | 3.3V (Typ.) |
|
|
Issiq teglar: mnf601ea1-1 Scre Ekran Muwund, Xitoy, zavod, arzon, LCD displey, 55 dyuymli LCD displey, Reklama displeyi, yuqori yorqin lcd displeyi Yetkazib beruvchi, avtobus stantsiyasi LCD ekran , LCD panel, LCD modul, yuqori yorqinlik displeyi.
