LG displey LD860DBN-UJA2 86YCACH UNVIVE Ko'rsatmasi LCD modul

To'lov turi:T/T,D/P,D/A,Paypal

Inkoerm:FOB,CFR,CIF,EXW

Min. Buyurtma:1 Piece/Pieces

Tashish:Ocean,Land,Air,Express

Port:Shenzhen

Mahsulot xususiyatlari
Ta'minot qobiliyati va qo'shimcha ma'lum...
Paket va etkazib berish
Other information

Mahsulot xususiyatlari

Model raqami: LD860DBN-UJA2

Size: 86-inches

Brightness: 700-nits

Ta'minot qobiliyati va qo'shimcha ma'lum...

Tashish: Ocean,Land,Air,Express

Port: Shenzhen

To'lov turi: T/T,D/P,D/A,Paypal

Inkoerm: FOB,CFR,CIF,EXW

Paket va etkazib berish

Sotish birliklari:

Piece/Pieces

Mahsulotni kiritish

Ld860dbn-uja2, Ushbu modulning ishlash harorati 0 ~ 50 ° C ni va saqlash harorati -20 ~ 60 ° C. Displeyning o'lchamlari 3840 (RGB) × 600, jihatlar nisbati (kengligi: kengligi) va piksellar RGB vertikal chiziqlarda joylashgan.

Ushbu LCD ekranining orqa yorug'ligi to'g'ridan-to'g'ri yorug'lik manbai va yorug'lik manbasining xizmat muddati 50K soatni ishlatadi. Raqamli imzoda, tashqi muhitda ishlatiladigan, kesik ekran va boshqa mahsulotlar.

Outdoor lcd module

Savol: Siz bizdan nima sotib olishingiz mumkin?

Javob: Semi-Outdoor LCD, tashqi ko'rinishi, ultrathin dekorativ LCD, LCD, Sud-LCD, TFT-LCD, LCD, yuqori yorug'likli LCD va boshqa yuqori darajadagi suyuqlik. LCD paneli.

Savol: Siz sotishdan keyingi va keyin qancha xizmat ko'rsatasiz?

Javob: Savdo-sotiq xizmati nuqtai nazaridan bizda 24 soat ichida savollaringizga javob berishga tayyor bo'lgan professional savdo jamoasi va texnik jamoamiz bor.

lcd panel display screen

brand	LG Display	Model name	LD860DBN-UJA2
size	86 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	3840(RGB)×600 45PPI	Pixel configuration	RGB vertical bar
Display Area	2148.48×335.7 mm (H×V)	Surface treatment	Fog surface(Haze 28%)，Hard coating (3H)
Visual size	2149.5×336.7 mm (H×V)	Contrast Ratio	1100:1 (Typ.) (TM)
Brightness(cd/m²)	700cd/m²(Typ.)or customized	Outline dimension	2158.3×348.5×82.2mm(H×V×D)
Viewing Angle	89/89/89/89 (Typ.)(CR≥10)	Backlight type	WLED, 50K hours, including LED driver
Signal interface	V-by-One 8 lane ,erminal,51 pins
work environment	Storage temperature: -20 to 60 °C Operation Temperature: 0to 50 °C

Issiq teglar: LG CH860DBNBN-UJA2 226VACH ORTIVE LCD, SFE Ekran, LCD displey, LCD displey, 1000 dona LCD displey, Ochiq kiyimlar paneli TV, LCD displey Buyuk Britaniya
