Ld860dbn-uja1 500 dona 86inch issiq sotish TFT-LCD paneli

To'lov turi:T/T,D/P,D/A,Paypal

Inkoerm:FOB,CFR,CIF,EXW

Min. Buyurtma:1 Piece/Pieces

Tashish:Ocean,Land,Air,Express

Port:Shenzhen

Mahsulot xususiyatlari
Ta'minot qobiliyati va qo'shimcha ma'lum...
Paket va etkazib berish
Other information

Mahsulot xususiyatlari

Tovar: Risordtar

Size: 86-inches

Brightness: 500-nits

Ta'minot qobiliyati va qo'shimcha ma'lum...

Hosildorlik: 150k

Tashish: Ocean,Land,Air,Express

Kelib chiqishi: Xitoy

Sertifikat: CE/ROSH/ISO9001

Port: Shenzhen

To'lov turi: T/T,D/P,D/A,Paypal

Inkoerm: FOB,CFR,CIF,EXW

Paket va etkazib berish

Sotish birliklari:

Piece/Pieces

Mahsulotni kiritish

Ld860dbn-uja1, TFT-LCD texnologiyasining 86 dyuymli suyuq kristall moduli, u yoritgichli yoritgich bilan jihozlangan, shu jumladan LED drayveri Orqagis haydovchisi, tegmadi.

Uning ish harorati 0 ~ 50 ° C va uning saqlash harorati -20 ~ 60 ° C. LD860DBN-UTA1-ni ko'rsatish rezolyutsiyasi 3840 (RGB) × 600, jihatlar nisbati - 3: 1 (kenglik: balandlik) va vertikal yangilanish tezligi 60 soat. Piksellar RGB vertikal chiziqlarda joylashtirilgan. Ushbu LCD ekran raqamli imzo, kesish panelini kesish uchun mos keladi.

LCD moduli

Savol: Biz sifatni qanday kafolatlashimiz mumkin?

Javob: Doim jo'natishdan oldin yakuniy tekshirish.

Savol: Boshqa o'lcham yoki spetsifikatsiyani tanlash mumkinmi?

Javob: Agar sizga har xil o'lcham yoki texnik kerak bo'lsa, biz sizning talablaringiz bo'yicha eng mos sxemani taqdim etamiz.

LCD panel displey ekranlari

brand	LG Display	Model name	LD860DBN-UJA1
size	86 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	3840(RGB)×600 45PPI	Pixel configuration	RGB vertical bar
Display Area	2148.48×335.7(H×V)mm	Surface treatment	Fog surface(Haze 10%)，Hard coating (3H)
Visual size	2149.5×336.7(H×V)mm	Contrast Ratio	1100:1 (Typ.) (TM)
Brightness(cd/m²)	500cd/m²(Typ.)or customized	Outline dimension	2158.3×348.5×82.2(H×V×D)mm
Viewing Angle	89/89/89/89 (Typ.)(CR≥10)	Backlight type	WLED, 50K hours, including LED driver
Signal interface	51 pins V-by-One 8 lane,erminal
work environment	Storage temperature: 0 to 50 °C Operation Temperature: -20to 60 °C
