21,5 dyuymli quyosh nuri Suyuq LCD paneli

Min. Buyurtma:1 Piece/Pieces

Mahsulot xususiyatlari
Ta'minot qobiliyati va qo'shimcha ma'lum...
Paket va etkazib berish
Other information

Mahsulot xususiyatlari

Tovar: Rissant

Ta'minot qobiliyati va qo'shimcha ma'lum...

Hosildorlik: 150KK

Kelib chiqishi: Shen zhen

Sertifikat: CE/ROSH/UL/ISO9001

Paket va etkazib berish

Sotish birliklari:

Piece/Pieces

Mahsulotni kiritish

Panel Brand	BOE	Panel Model	MT220WPM-N10
Panel Size	22.0"	Panel Type	a-Si TFT-LCD , LCM
Resolution	1680(RGB)×1050, WSXGA+, 90PPI	Pixel Format	RGB Vertical Stripe
Display Area	473.76(W)×296.1(H) mm	Bezel Opening	477.7(W)×300.1(H) mm
Outline Size	493.7(W)×320.1(H) ×10.7(D) mm	Surface	Antiglare (Haze 25%), Hard coating(3H)
Brightness	1000nit or customized	Contrast Ratio	1000:1 (Typ.) (TM)
Viewing Angle	85/85/80/80 (Typ.)(CR≥10)	Display Mode	TN, Normally White, Transmissive
Display Colors	16.7M 72% NTSC	Response Time	1.5/3.5 (Typ.)(Tr/Td)
Frequency	60Hz	Lamp Type	3 strings WLED , 40K hours , Without Driver
Weight	1.83Kgs (Typ.)	Touch Screen	Without
Signal Interface	LVDS (2 ch, 8-bit) , 30 pins Connector
Input Voltage	5.0V (Typ.)
Environment	Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -25 ~ 60 °C

Ultra-ingichka lCD paneli, yorqinlik 1000itga etadi, rasm hali ham to'g'ridan-to'g'ri quyosh nuri va deraza modulida tozalangan, bu quyosh nuri uchun eng yaxshi echim, quyosh nuri kabi sodda bo'lishi mumkin: 600-1000it.

Yorqin-yorug '-yorqinlik-monitor-imzolage-id_1559693827636_03

21,5 dyuymli displey LCD displeyi baland yorqinlik LED LED belgisi bilan

1, yoritgich modul tuzilishi : barcha alyuminiy tuzilishi, engil va ingichka, yaxshi ko'rinishi, samarali isitish tarqalishi.

2, LED yoritgi : Oq LED boncuklari, baland yorqinlik, 50k HRSning ishlashi, mukammal yorqinlik bir xilligi.

3, Yorug'lik chizig'ini yig'ish : Alyuminiy tuzilmasi yoritilgan yoritgichni issiqlik o'tkazuvchanligiga ko'maklashish uchun alyuminiy tuzilmasini tuzating.

4, Fans lampasi : Alyuminiy tuzilmasi yoritilgan yoritgich, alyuminiydagi LED yoritmasini tuzating

21,5 dyuym yorug'lik LCD moduli Quyosh nuri LCD-panel

Ultra silliqi 21,5 dyuymli LCD modullari simlarni ulang va orqa chiroqning asl brend ochiq hujayrali ko'proq formada bir xil ko'rinishga ega bo'lish uchun 3M aks ettiruvchi plyonkalarni ulang. 10,000 sinfli toza xonani kiriting va LED ning orqa chiroqlari normal ishlashini ta'minlash uchun yorug'likni tekshiring.

Ultra shlim 0,5 dyuymli LCD modulini optik tekislar bilan

Yupqa yorqin lcd moduli optik tekislar: diffuziya plastinka, tarqoq plyonka, porlashni yaxshilash plyonkasini yaxshilash va qo'shimchalarni yoritishni yaxshilash.

LGD / Samsung / AUO / BOE / Boo / HUE HRD modulini juda yaxshi

Ushbu silliq 21,5 dyuymli LCD modul LG / Samsung / AUO / AUO / AUO / AUO / BOE / HOZASIYA HUJJATLARI FOYDALANISHI (Oddiy navli va sanoat darajasi yuqori darajadagi tni110 ℃)

Ultra silliqi 21,5 dyuymli LCD modul t-konlar kengashi bilan

21,5 dyuymli LCD moduli T-Con Kengash, Lead drayveri boshliqlari, doimiy DC12v elektr ta'minoti.

Yorqinlik sinovi bilan 21,5 dyuym yuqori darajadagi modul

Ushbu nozik yorug'lik 21,5 dyuymli LCD moduli yorqinlik sinovidan o'tdi, rang haroratining yorqin testi, "BM-7 rang" Rangning yorqin sinovchisi.
