15.4 dyuym Samsung LTN154x9-L01

Min. Buyurtma:1 Piece/Pieces

Mahsulot xususiyatlari
Paket va etkazib berish
Other information

Mahsulot xususiyatlari

Model raqami: LTN154X9-L01

Paket va etkazib berish

Sotish birliklari:

Piece/Pieces

Mahsulotni kiritish

LTN154x9-L01 Ushbu modul CCFL yoritgich bilan jihozlangan, Backlight drayveri yo'q, tegmadi. Uning odatiy xususiyatlari: oyna yuzasi. Uning ish harorati 0 ~ 50 ° C va uning saqlash harorati -20 ~ 60 ° C.

LTN154x9-L01 displey o'lchamlari 1280 (RGB) × 800 (WXGA), jihati 16:10 (kengligi) va piksellar RGB vertikal chiziqlarda joylashgan. Uning displey maydoni 331,2 × 207 (kengligi × balandligi) - 335,0 × 210.7 (kengligi × (balandligi) × qalinligi (qalinligi) × 7 (qalinligi). Ko'zgu yuzasiga (Nazorat 0%), qattiq qoplama (3h).

10.1 inch panel

Savol: Siz sotishdan keyingi va keyin qancha xizmat ko'rsatasiz?

Javob: Savdo-sotiq xizmati nuqtai nazaridan bizda 24 soat ichida savollaringizga javob berishga tayyor bo'lgan professional savdo jamoasi va texnik jamoamiz bor.

Savol: Qanday qilib to'g'ri mahsulotni topsam bo'ladi?

Javob: Iltimos, bizga talablaringizni yuboring, agar u mos kelmasa, biz kerakli sozlash va xususiylashtirishni amalga oshiramiz.

Yuqori yorqin lcd

brand	SAMSUNG	Model name	LTN154X9-L01
size	15.4 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1280(RGB)×800	Pixel configuration	RGB vertical bar
Display Area	331.2×207(H×V)mm	Surface treatment	Glare (Haze 0%), Hard coating (3H)
Visual size	335.0×210.7(H×V)mm	Contrast Ratio	600:1 (Typ.) (TM)
Brightness(cd/m²)	500cd/m²(Typ.)or customized	Outline dimension	344×226×7(H×V×D)mm
Viewing Angle	65/65/50/50 (Typ.)(CR≥10)	work environment	Storage temperature: -20 to 60 °C Operation Temperature: 0 to 50 °C
Signal interface	LVDS (1 ch, 6-bit) ,erminal,30pins
supply voltage	12.0V (Typ.)
