Model raqami: LA123WF4-SR03
LA123WF4-SR03 ning ish harorati -40 ~ 85 ° C, saqlash harorati -40 ~ 95 ° C. LA123WF4-SR03 displeyi 1920 (RGB) × 720, va yo'nalishi 8: 3 (kengligi: kengligi), piksellar RGB vertikal chiziqlarda joylashgan.
LA123WF4-SR03 displey maydoni 292.032 × 109.512 (W × 16.5) mm va tashqi ko'rinishi 310 (W) × 108 (soat 10.75) D) mm, sirtni davolash qiyin qoplama.
Turli ekologik ehtiyojlarni qondirish uchun standartlashtirish va sozlash.
Rising-Star Umumiy ko'rgazma panellari ultra yuqori aniqlikdagi, tashqi ko'rinishi va uzoq navli hayotga ega. Mahsulot dasturlari Avtomatik telefoniy (ATM), Terminal Sotish dastgohlari, interfaol ma'lumotlarning kiosklari (Kiosk), Siyosat-ko'ngilochar kiosklar, tibbiy asbob-kulgi mashinalari, parvozi avtomatlashtirish Marine kutmoqda. Shuningdek, mijozlarga raqobatdosh terminal qurilmalarini ishlab chiqishda yordam beradigan maxsus dizayn va o'rnatilgan teginish echimlarini ham taqdim etamiz.
| brand | LG Display (LG Display) | Model name | LA123WF4-SR03 |
| size | 12.3 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution | 1920(RGB)×720 167PPI | Pixel configuration | RGB vertical bar |
| Display size | 292.032×109.512(H×V)mm | Surface treatment | Hard coating |
| Brightness(cd/m²) | 600 cd/m² (Min.) or customized | contrast | 800:1 (Min.) (TM) |
| Viewing Angle | 89/89/89/89 (Min.)(CR≥10) | Appearance of size | 310×128×10.75mm(H×V×D) |
| Signal system | RSDS (2 Channel) , 110 pins , FPC | ||
| Maximum rated | Storage temperature: -40 ~ 95 °C Working temperature: -40 ~ 85 °C Vibration resistance: 3.0g (29.4m /s²) |
Issiq teglar: LG displey 12.3 "LA123WF4-SR03 LCD displeyasi, Xitoy, zavod, lCD panel, Chiqish derazasi, LCD displey, 12 1 dyuym LCD, yuqori yorqin LCD displey etkazib beruvchi
