Min. Buyurtma:1 Piece/Pieces
UV215FM-N10 - A-SI TFT-LCD texnologiyasi bilan 21,5 dyuymli suyuq kristall modul, 1920 (RGB) × 1080 (kengligi) va pikseli RGB vertikal chiziqlarda joylashtiriladi. Uning displey maydoni 476,64 × 268.11 (× h) mm, ko'rinadigan o'lcham 479,8 × 292,2 (H) × 11.2 (d) mm.
Mott kabi davolanadi (25% ni), qattiq qoplama (3H), ish harorati -20 ~ 80 ° C, 85 ° C. Raqamli imzo qo'yish uchun. EDGE-Tyunig Strial manbasi, yorug'lik manbasining xizmat muddati 30K soatni tashkil qiladi, bu esa terminal ulanishidan foydalangan holda, drayver kuchlanishi 5.0V (TUZA). .
Savol: Boshqa o'lcham yoki spetsifikatsiyani tanlash mumkinmi?
Javob: Agar sizga har xil o'lcham yoki texnik kerak bo'lsa, biz sizning talablaringiz bo'yicha eng mos sxemani taqdim etamiz.
Savol: Siz sotishdan keyingi va keyin qancha xizmat ko'rsatasiz?
Javob: Savdo-sotiq xizmati nuqtai nazaridan bizda 24 soat ichida savollaringizga javob berishga tayyor bo'lgan professional savdo jamoasi va texnik jamoamiz bor.
Savol: Qanday qilib uzoq muddatli biznes aloqalarini saqlay olamiz?
Javob: Biz mijozlar foydasiga imkoniyat berishini ta'minlash uchun sifatli va raqobatbardosh narxlarni saqlaymiz; Biz har bir mijozni hurmat qilamiz va ularga do'st sifatida munosabatda bo'lamiz. Qaerda bo'lishidan qat'i nazar, biz ular bilan chin dildan biznes va do'stlar orttiramiz.
| brand | BOE | Model name | UV215FHM-N10 |
| size | 21.5 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1920(RGB)×1080 FHD 102PPI | Pixel configuration | RGB vertical bar |
| Display Area | 476.64×268.11(H×V)mm | Surface treatment | Fog surface(Haze 25%)，Hard coating (3H) |
| Visual size | / | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 495.6×292.2×11.2mm(H×V×D) |
| Viewing Angle | 89/89/89/89(Typ.)(CR≥10) | ||
| Signal interface | 30 pins LVDS (2 ch, 8-bit),erminal | ||
| work environment | Storage temperature: -30 to 85 °C Operation Temperature: -20 to 80 °C |
Bir xil o'lchamdagi modelning parametrlari
| brand | BOE | Model name | DV215FHM-R01 |
| size | 21.5 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1920(RGB)×1080 FHD 102PPI | Pixel configuration | RGB vertical bar |
| Display Area | 476.64×268.11(H×V)mm | Surface treatment | Fog surface(Haze 25%)，Hard coating (3H) |
| Open zone | 479.8×271.3(H×V)mm | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 495.6×292.2×11.2mm(H×V×D) |
| Viewing Angle | 89/89/89/89(Typ.)(CR≥10) | ||
| Signal interface | 30 pins LVDS (2 ch, 8-bit),erminal | ||
| work environment | Storage temperature: -20 to 85 °C Operation Temperature: -20 to 85 °C |
