Mahsulot xususiyatlari

Model raqami: EV101WXM-N81

Paket va etkazib berish

Sotish birliklari:

Piece/Pieces

Mahsulotni kiritish

EV101WXM-N81 - A-SI TFT-LCD texnologiyasidan foydalangan holda 10,1 dyuymli LCD modulidir. U yoritgichli yoritgich bilan jihozlangan, shu jumladan LED Drive Drive Drive, tegmadi. Ko'rsatilgan o'lchamlari 1280 (RGB) × 800 (WXGA), jihati nisbati 16:10 (kengligi) va piksellar RGB vertikal chiziqlarda joylashtirilgan. Uning displey maydoni 216,96 × balandlik) mm, vizual o'lcham 219,4 × 152.9 (kengligi × balandligi) × 40 balandlik) (To'g'ri.). Aktsiyani yoritish nuqtai nazaridan, ushbu mahsulot 50K soat, shu jumladan LED drayveri bo'lgan WALD yon tomonini kiritish manbasini ishlatadi. EV101WXM-N81 Jami 20 tagacha pinlar, jami 20 ta yoki terminal ulanishidan foydalanadi, drenaj ekran kuchlanishi 3,3v. Uning odatiy vertikal yangilanish stavkasi FV - 60Hz. U -20 ° C dan 70 ° C gacha va 80 ° C gacha bo'lgan do'konlar ishlaydi. Oq bo'yidagi oq nuriga asoslanib, hayot 50 000 soatdan oshadi.

R-yulduz Shenzhen, Xitoy, LCD-ning yuqori darajadagi LCD-ning professional ishlab chiqaruvchisi, shu jumladan 10.1 dan 120 dyuymgacha bo'lgan SFFL-LCD modullari, shu jumladan tashqi ko'rinishi, tashqi ko'rinishi, ochiq havoda bo'linish LCD, Sanoat yo'nalishi TFT-LCD, shaffof kristalli va displen ramkasi, yuqori darajadagi suyuq kristalli LCD va boshqa yuqori darajadagi LCD paneli. Qisqasi, ko'tarilish 5 yildan ortiq baland yorqinlik tajribasi, 8 yillik yirik TFT moduli dizayn, tadqiqotlar va ishlab chiqish, ishlab chiqarish va ishlab chiqish, 10 yillik yuqori sifatli xom ashyo ta'minoti zanjiri mavjud.

brand	BOE	Model name	EV101WXM-N81
size	10.1 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1280(RGB)×800, WXGA, 149PPI	Pixel configuration	RGB vertical bar
Display Area	216.96×135.6(H×V)mm	Surface treatment	/
Visual size	233.2×152.9×10.4(H×V×D) mm	Contrast Ratio	900:1 (Typ.) (TM)
Brightness(cd/m²)	500cd/m²(Typ.)or customized	Outline dimension	233.2×152.9×10.4(H×V×D)mm
Viewing Angle	85/85/85/85 (Typ.)(CR≥10)
Signal interface	LVDS (1 ch, 8-bit) ,erminal, 20 pins
work environment	Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C

Bir xil o'lchamdagi model va parametrlar quyidagicha

brand	BOE	Model name	EV101WUM-N20
size	10.1 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1920(RGB)×1200, WUXGA, 224PPI	Pixel configuration	RGB vertical bar
Display Area	216.806×135.504mm(H×V)	Surface treatment	/
Visual size	/	Contrast Ratio	900:1 (Typ.) (TM)
Brightness(cd/m²)	600cd/m²(Typ.)or customized	Outline dimension	229.45×149.22(H×V)mm
Viewing Angle	80/80/80/80(Typ.)(CR≥10)
Signal interface	LVDS (1 ch, 8-bit) ,erminal, 45 pins
work environment	Storage temperature: -25 to 80 °C Operation Temperature: -20 to 70 °C

brand	BOE	Model name	AT101WSM-N11-58P0
size	10.1 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1024(RGB)×600, WSVGA, 117PPI	Pixel configuration	RGB vertical bar
Display Area	222.72×125.28mm(H×V)	Surface treatment	Fog surface，Hard coating (3H)
Visual size	226×128.6(H×V)mm	Contrast Ratio	500:1 (Typ.) (TM)
Brightness(cd/m²)	500cd/m²(Typ.)or customized	Outline dimension	235×144.9×5.44mm(H×V×D)
Viewing Angle	80/80/60/70(Typ.)(CR≥10)
Signal interface	LVDS (1 ch, 6/8-bit) , 60 pins , FPC
work environment	Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C

brand	BOE	Model name	EV101WXM-N82
size	10.1 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1280(RGB)×800 [WXGA] 149PPI	Pixel configuration	RGB vertical bar
Display Area	216.96 × 135.6 mm (H×V)	Surface treatment	/
Visual size	/	Contrast Ratio	900:1 (Typ.) (TM)
Brightness(cd/m²)	500cd/m²(Typ.)or customized	Outline dimension	228.6 ×149.2×6 mm (H×V×D)
Viewing Angle	85/85/85/85(Typ.)(CR≥10)
Signal interface	LVDS (1 ch, 8-bit) ,erminal, 40 pins
work environment	Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C
