Boe ba104S01-100 yorqinlik 500 dona TFT-LCD paneli

Min. Buyurtma:1 Piece/Pieces

Mahsulot xususiyatlari
Paket va etkazib berish
Other information

Mahsulot xususiyatlari

Model raqami: BA104S01-100

Paket va etkazib berish

Sotish birliklari:

Piece/Pieces

Mahsulotni kiritish

Ba104s01-100 - LCD modulli mahsulot - Boe Technology Group Co., Ltd tomonidan ishga tushirilgan mahsulotni ishlab chiqaradi. (Boe) A-SI TFT-LCD texnologiyasidan foydalangan holda. U Wedl chiroqlari bilan jihozlangan, aks holda yoritgich va teginish yo'q. Ba104S01-100 800 (RGGA) ning 4: 3 (kengligi) ni ko'rsatadi. .1 Boe tomonidan 2014 yil 12 dekabrda e'lon qilingan × 5.9 (qalinligi) mm, sirtni davolash aniq, mahsulotning quyi og'irligi 288g (Tavsif.). Backlight Ushbu mahsulotda 6S6P WALD ™ arizasi yorug'ligi (tepasi), yorug'lik manbai 50 kilogramm, yorug'lik drayveri yo'q. Ba104s01-100 LVDS (1 Ch, 6-bit) signal interfeysini qabul qiladi, jami 20 ta pinni qabul qiladi, terminal ulanishini qabul qiladi, drayver ekran kuchlanishi 3,3v. Uning odatiy vertikal yangilanish stavkasi FV - 60Hz. U -20 ° C dan 70 ° C gacha va 80 ° C gacha bo'lgan do'konlar ishlaydi. Ushbu model oq gangining yoritgichlari, 50 000 soatdan ortiq hayot, terminal flip, 6/8 bitim va boshqa xususiyatlar uchun foydalanish uchun tavsiya etiladi.

brand	BOE	Model name	BA104S01-100
size	10.4 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	800(RGB)×600 [SVGA] 96PPI	Pixel configuration	RGB vertical bar
Display Area	211.2×158.4 mm (H×V)	Surface treatment	Clear
Visual size	215.0×162.0 mm (H×V)	Contrast Ratio	800:1 (Typ.) (TM)
Brightness(cd/m²)	500cd/m²(Typ.)or customized	Outline dimension	236×176.9×5.9 mm (H×V×D)
Viewing Angle	70/70/60/70 (Typ.)(CR≥10)
Signal interface	LVDS (1 ch, 6/8-bit) ,erminal, 20 pins
work environment	Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C

Quyida bir xil o'lchamdagi modellar va parametrlar

brand	BOE	Model name	AV104X0M-N10
size	10.4 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1024(RGB)×768 (XGA) 123PPI	Pixel configuration	RGB vertical bar
Display Area	210.4 × 157.8 (H×V) mm	Surface treatment	/
Visual size	215.4 × 161.8 (H×V) mm	Contrast Ratio	1100:1 (Typ.) (TM)
Brightness(cd/m²)	600cd/m²(Typ.)or customized	Outline dimension	230 × 180.2(H×V)
Viewing Angle	85/85/85/85 (Typ.)(CR≥10)
Signal interface	LVDS (1 ch, 6/8-bit) ,erminal, 20 pins
work environment	Storage temperature: -40 to 95 °C Operation Temperature: -30 to 85 °C

brand	BOE	Model name	TDA104-001V02
size	10.4 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1024(RGB)×768 (XGA) 123PPI	Pixel configuration	RGB vertical bar
Display Area	210.4 × 157.8 (H×V) mm	Surface treatment	/
Visual size	/	Contrast Ratio	1000:1 (Typ.) (TM)
Brightness(cd/m²)	900cd/m²(Typ.)or customized	Outline dimension	235×173×10.5mm(H×V×D)
Viewing Angle	85/85/85/85 (Typ.)(CR≥10)
Signal interface	LVDS (1 ch, 8-bit) ,erminal, 20 pins
work environment	Storage temperature: -55 to 85 °C Operation Temperature: -40 to 80 °C

10.4 inch panel
