Min. Buyurtma:1 Piece/Pieces
Tovar: Risordtar
Hosildorlik: 200K
Kelib chiqishi: Shenzhen
Sertifikat: CE/ROSH/UL/ISO9001
RezingStar LCD displey modul, Resyulotion 1280 * 1024, 0,0 dyuymli LCD-modulli mahsulotlar, shu jumladan LED drayveri yoritgich bilan jihozlangan. LCD panel istagan vaqtda aniq o'qiy olsin.
17VD displey modulining 1280 (RGB) × 1024 (SXga), jihati 5: 4 (kengligi) va piksellar RGB vertikal chiziqlarda joylashgan. Displey maydoni: 337.92 × balandlik) mm, maydoni: 341,6 × balandligi (kengligi × balandligi) × 18 (qalinligi) mm. Sirtni davolash - bu tuman sirtidir (3h), aks holda yoritilgan, bu mahsulot 50k soat davomida WALL yonidagi kirish manbasi (tepasi).
17VD displey modullari:
- kvadrat SFC paneli, jihati nisbati: 5: 4
- O'qish mumkin bo'lgan
- 1500 donagacha yorqinlik
- o'z-o'zini rivojlangan LED yoritgich texnologiyasi
--24 / 7 ish vaqti
- Quvvat sarfi
|
Model Name |
RS170NET-N05 |
|
Description |
17" TFT LCD,500nits LED backlight |
|
size |
17" |
|
Display area (mm) |
337.92(H) x 270.336(V) |
|
Brightness |
350-1500cd/m² |
|
Resolution |
1280*1024 |
|
Aspect ratio |
5:4 |
|
Contrast ratio |
1000:1 |
| Viewing angle |
85/85/80/80 |
|
Color saturation (NTSC) |
72% |
|
Display colors |
16.7M |
|
Video interface |
LVDS(2 ch, 8-bit) ,30pin |
|
Dimensions (mm) |
358.5*295.5*18 |
|
Weight (Net) |
1.3kg |
|
Customized |
Brightness, Color, Size |
Issiq teglar: 1280 * 1024 17 dyuymli LCD displey modul, Xitoy, zavod, arzon, kvadrat, 55 dyuymli displey, Seed LCD displey, SMI Ochiq ekran, LCD paneli 2500 nits , 43 dyuymli ochiq panel , LCD panel, LCD modul, yuqori yorqinlik displeyi.
1000 nits LCD displey ekran 15 dyuym
16: 9 17 dyuymli LCD displey modul
