Min. Buyurtma:1 Piece/Pieces
Tovar: Risordtar
Hosildorlik: 500K
Kelib chiqishi: Shenzhen
Sertifikat: CE/ROSH/UL/SIO9001
800 nits LCD moduli, modul o'lchami 13.3inch, bu modul - bu oksid tff (ingichka kino tranzistorti) ni o'z ichiga olgan rangli matrix modulidir. TFT-LCD paneli, drayver ECC, boshqaruv zonasi va elektr ta'minotini boshqarish, 1920 * 1080.
Axborot to'liq etkazilishi uchun 800 dona LCD moduli tomoshabinga taqdim etilishi va bu vizual effekt tomoshabinni ta'sirli qilishi mumkinligini ta'minlaydi.
13,3 dyuymli LCD moduli transport vositalarida, sanoat nazorati displeylarida, elektron klass kartalari, yangi energiya zaryadlash qozoni va boshqalarni keng qo'llaniladi.
Ilova:
| Size | 13.3inch |
| Panel item | RS133NET-N10 |
| Panel type | a-Si TFT-LCD |
| Display mode | IPS,Normally black，transmissive display |
| Pixels | 1920*1080 |
| brightness | 1000cd/m2 |
| Constrast Ratio | 800：1 |
| Response Time | 25ms |
| View angle | 89/89/89/89 |
| View area | 295.07*166.68mm(H*V) |
| Dispaly area | 293.472*165.078mm(H*V) |
| Outline Size | 309.7*184.1*10.1mm(H*V*D) |
| Signal Type | LVDS,30Pin |
| Working freqyency | 60Hz |
| Working temperature | 0- 70ﾟC |
| Storage Temperature | -25- +65.0ﾟC |
| Display ratio | 16:9 |
| Display color | 16.7m |
| Nominal Input Voltage | 3.3V |
| Surface Treatment | Haze |
| Weight | 0.5kgs |
