Min. Buyurtma:1 Piece/Pieces
Size: 10.1 inch
Brightness: 1000 nits
Contrast Ratio: 1000:1
Resolution: 1280*800
Operating Temperature: -10 - 50°C
Kichik o'lchamli tashqi ko'rinishi, tashqi ko'rinishi, 10,1 dyuymli TFT 1000 nits LCD monitori. Ekranda ko'rsatilgan tarkib yaxshi yoritilgan muhitda aniq ko'rinib turibdi, ularni har xil zaryadlash dastgohlari, o'z-o'ziga xizmat ko'rsatish mashinalari, kiosklar va boshqa server terminallari bilan ishlatilishi mumkin.
Agar sizda boshqa ehtiyojlar bo'lsa, iltimos biz bilan bog'laning, biz sizning ehtiyojlaringizga qarab eng mos suyuq kristalli displey echimni sozlaymiz.
O'rnatilgan ochiq havoda mahsulot xususiyatlari
10.1 "TFT LCD paneli
1280 * 800 Qaror
tashqi tomondan, 500 donadan 1500 funtgacha bo'lgan yorqinlik
2 mm, temperli shisha qattiq va vandal isumi uchun ishonchli
VGA HDMI DVI USB interfeysi
Yuqori ishlab chiqarish taxtasi, 7/24 Uzluksiz operatsiya
Qo'llab-quvvatlash 12-24V keng kuchlanish
Ultra-ingichka oldingi Bezel 3mm, o'rnatilgan o'rnatish uchun ideal
Old panel IP55 suv o'tkazmaydigan changning oldini olish
Keng haroratning keng ishlashi: -10 - 50 ° C
|
Product specification |
|
|
LCD panel |
|
|
Panel size |
10.1" |
|
Resolution |
1280*800 or 1024*600 |
|
Support Color |
16.7M colors |
|
Brightness (cd/m²) |
1000 nits (can be customized) |
|
Contrast ratio |
1000:1 |
|
View angle |
80°/80°/80°/80° (R/L/U/D) |
|
Touch panel |
|
|
Touchscreen Type |
Capacitive Touch (10 points ) |
|
Surface Hardness |
7H |
|
Luminousness |
90% |
|
Touch Interface |
USB (RS232 optional) |
|
Touch response time |
2ms |
|
Working Life |
>50 million times |
|
OSD |
|
|
OSD control |
Brightness, contrast ratio, auto adjustment, H/V position, language select, etc. |
|
Support languages |
English, French, Spanish, Portuguese, Italian, German, Russian, Japanese, Chinese, etc. |
|
Support OS |
Windows ,HDMI, Android, ect. |
|
Power Supply |
|
|
External Power Supply |
AC 100 - 240V, 50-60Hz |
|
Working voltage |
DC 12-24V |
|
Power consumption |
≤35W |
|
Enclosure |
|
|
Material |
Aluminum Alloy |
|
Color |
Black, Silver or customized |
|
VESA mounting |
75x75mm/100x100mm |
|
IP grade |
Front panel IP55 waterproof |
|
Operating Environment |
|
|
Temperature Range |
operating: -10 to 50°C, storage: -20 to 80°C |
|
Relative humidity |
operating: -5% to 95%, storage: -5% to 95% |
|
Packing Details |
|
|
Gross weight |
about 4kg |
|
Accessories |
Power adapter, VGA cable, USB touch cable, embedded screws |
|
Other |
|
|
Mounting |
embedded mounting screws |
|
wall mounting brackets (optional) |
|
|
desk stand holder (optional) |
|
|
Warranty |
1 year warranty |
|
Certificates |
CE, 3C, RoHS |
